Specification	Value
Additional Information	0.032 in Tube Wall Thickness, 0.12 lb Weight
Connection Size 1	1/2 in
Connection Size 2	3/8 in
Connection Type	Female SAE Flared|Female SAE Flared
Connection Type 1	SAE 45 deg Female Flared
Connection Type 2	SAE 45 deg Female Flared
Dimensions	1.54 in L
Fitting Type	Union
For Use With	Aluminum, Brass, Copper, Steel Hydraulic Tubing That Can Be Flared
Hex Size	0.94 x 0.81 in
Material	Brass
Material Construction	Brass
Pressure Rating	750 psi
Temperature Rating	-65 to 250 deg F
Thread Size	3/4-16 x 5/8-18
